KIS-1
Chunlai
KIS-1 Desktop Paper Cup Pre-cut Aluminium Foil Sealing Machine is a tabletop model with heat sealing features. Very compact, it is a drawer style cup sealer that seals pre-cut aluminum foil with a pneumatic piston. As you push in the drawer holding your food-filled cups, the machine seals over the cups
The temperature are regulated to allow for the sealing of different types of film and trays. . It can seal trays made of PP, PE, CPET, APET and Aluminum.
APPLICATION
1. For Round Cup/Bowl sealing: Water, Hummus, Juice, Jelly, Yogurt, Pudding...
2. For Square Tray sealing : Lunch box, Tofu, Fresh frozen food, Sea food, sandwich, agricultural processed product...
3. Or any others: Cosmetics and Pharmaceutical product .Many kinds of packaging product by Plastic or Paper container.
Main Function:
machine slide mould automatically
put cup on mould manually
put aluminum foil automatically on cup
machine slide mould automatically
pneumatic sealing
machine slide mould automatically
take cup outside mould manually
KIS-1 Desktop Paper Cup Pre-cut Aluminium Foil Sealing Machine is a tabletop model with heat sealing features. Very compact, it is a drawer style cup sealer that seals pre-cut aluminum foil with a pneumatic piston. As you push in the drawer holding your food-filled cups, the machine seals over the cups
The temperature are regulated to allow for the sealing of different types of film and trays. . It can seal trays made of PP, PE, CPET, APET and Aluminum.
APPLICATION
1. For Round Cup/Bowl sealing: Water, Hummus, Juice, Jelly, Yogurt, Pudding...
2. For Square Tray sealing : Lunch box, Tofu, Fresh frozen food, Sea food, sandwich, agricultural processed product...
3. Or any others: Cosmetics and Pharmaceutical product .Many kinds of packaging product by Plastic or Paper container.
Main Function:
machine slide mould automatically
put cup on mould manually
put aluminum foil automatically on cup
machine slide mould automatically
pneumatic sealing
machine slide mould automatically
take cup outside mould manually
Production Capacity | 300-400 times/hour |
Voltage | 220V 50Hz |
Power | 2 Kw |
Air consumption | 0.4 m3/min |
Dimension | 900mmX800mmX1850mm |
Weight | 100 kg |
Production Capacity | 300-400 times/hour |
Voltage | 220V 50Hz |
Power | 2 Kw |
Air consumption | 0.4 m3/min |
Dimension | 900mmX800mmX1850mm |
Weight | 100 kg |
Machine Frame: Stainless Steel
Bottom Molds: Aluminum Alloy
PLC: Mitsubishi
Cylinder: AirTac
Solenoid valve: Mindmand
Switch: IDEC
Machine Frame: Stainless Steel
Bottom Molds: Aluminum Alloy
PLC: Mitsubishi
Cylinder: AirTac
Solenoid valve: Mindmand
Switch: IDEC
Can be customized with roll film sealing
Can be customized with roll film sealing
pre-cut aluminum foil seal
roll film sealing
square tray sealing
pre-cut aluminum foil seal
roll film sealing
square tray sealing
